Machine Straight Link Welded Steel Chain (NACM90)

Finish: Self Colored, Zinc Plated

Produced to the NACM standards

Do not use in overhead lifting applications

Machine Straight Link Welded Steel Chain (NACM90) is a type of chain that is commonly used in overhead lifting applications, as well as in general-purpose applications where moderate strength and durability are required.

The “welded” construction of the chain means that each link is fused together using a welding process rather than simply being interlocked. This provides additional strength and security, as there are no weak points where the links could come apart.



Trade Size		Material Diameter		Nominal Inside Length		Nominal Inside Width		Work Load Limit (MAX.)		Proof Test (MIN.)		Breaking Force (MIN.)
	mm	in	mm	in	mm	in	mm	LBS	KG	LBS	KN	LBS	KN
4	3.0	0.120	3.0	0.55	14.0	0.21	5.3	215	98	430	1.91	860	3.82
3	3.4	0.135	3.4	0.59	15.0	0.24	6.1	270	122	540	2.40	1080	4.80
2	3.8	0.148	3.8	0.61	15.5	0.26	6.6	325	147	650	2.89	1300	5.78
1	4.1	0.162	4.1	0.63	16.0	0.28	7.1	390	177	780	3.47	1560	6.93
1/0	4.5	0.177	4.5	0.74	18.8	0.31	7.9	465	211	930	4.14	1860	8.27
2/0	4.9	0.192	4.9	0.78	19.8	0.34	8.6	545	247	1090	4.85	2180	9.69
3/0	5.3	0.207	5.3	0.85	21.6	0.36	9.1	635	288	1270	5.65	2540	11.29
4/0	5.5	0.218	5.5	0.99	25.1	0.38	9.6	700	318	1400	6.23	2800	12.44
5/0	6.4	0.250	6.4	1.07	27.2	0.44	11.2	925	420	1850	8.23	3700	16.44
